60 TBP Z drive Tug

z drive tug for sale

Vessel ID: 050918E

General

Built: 2007

Class: LR, + 100A1 LR, Tug, + LMC, UMS



Dimensions

Length: 27.4 m

Beam: 11.5 m

Depth: 5.0 m

Draft: 5.2 m

GRT: 327

NT: 98



Performance

Speed:12.5 knots

Bollard pull: 60.0 t



Machinery

Main engines: 2 x Cat 3516NB, 1865 kW each

Propulsion: 2 x Schottel, SRP 1215FP

Generators: 2 x 112 kW Perkins 6WMGT @ 1500 rpm

Propulsion:  Z Drive Schottel SRP 1215FP



Deck equipment

Tow winch: Plimsoll PR-HTW/DD – 20T

Brake holding: 150 tonnes

Line pull: 5.0MT @ 20m/min

Anchor windlass: 2 x Plimsoll PC – HNW/SD – 319

Deck crane: Palfinger 1.5T @ 6m



Fire Fighting

Fifi pump:  1 x ABS SFP 1,400 m3 @ 125 m head c/w water curtain

Monitors:  2 x SKUM type FFS1200 dual purpose foam/water 600m3/hr each



Tank Capacities

Fuel: 110 m3

Fresh Water: 23 m3

Dispersant: 3.0 m3

Foam: 3.0 m3



Navigation and Communication

Radar: Furuno FR-1942 Mark 2

SSB transceiver:  Furuno FS-2570C

VHF: 1 x Motorola GM338, 1 x Furuno FM-8800S

Echo Sounder: Furuno FCV-581L

Immarsat C: Felcom 15

Navtex: Furuno NX-700B

EPIRB:  McMurdo E3 406MHz
Talkback system: SEA 857

Magnetic compass: Dirigo WA98005

Auto pilot: Com Nav 2001



Accommodation

Cabins: 2 x 1 berth, 1 x 2 berth, 2 x 3 berth, 10 berths in total

Other: Galley, mess room, sanitary facilities, air conditioned

Sewage system: Taiko Kikai SBT-15



Location: Singapore, available now

 POA

Sistership 60TBP Z Drive Tug    Find out more

z drive tug for sale

As brokers only. Details believed to be correct but not warranted. A buyer or charterer should investigate or verify the details, or instruct their agents or surveyors to do so, as the buyer or charterer desires validated, prior to entering into any kind of a commitment. This vessel is offered subject to prior sale or charter, price change or withdrawal without notice.
